Parts from the
Mack SS44/SWS57 Camelback Rear Suspension
Login: Visitor@nsihd.com #1: Cash/Counter Customer
Pic Description Wt
 3 1/2" Spindle w/ 3 5/16"-12 Threads 48 3/4" Long 134.00
MA11A
MA11AMA11A

Photos are for reference only; the actual part may show minor variances from the picture

Trunnion 59.10
M-1414
M-1414M-1414

Photos are for reference only; the actual part may show minor variances from the picture

Grease Zerk Strt 1/8 Pipe 0.02
  3 1/2" Trunnion Maintenance Kit
Parts
4-MA9Z, 2-MA10B, 4-MA10C, 2-MA10D, 2-MA10H, 2-MA10J,
16.92
MA9Z
MA9ZMA9Z

Photos are for reference only; the actual part may show minor variances from the picture

Bronze Trunnion Bushing 3 3/4"x3 1/2"x3 7/16" 1.55
MA10C
MA10CMA10C

Photos are for reference only; the actual part may show minor variances from the picture

Bronze Washer 5 ¼" x 3 ½" x ¼" 0.92
MA10J
MA10JMA10J

Photos are for reference only; the actual part may show minor variances from the picture

Washer 5 3/8" x 3 ½" x 5/16" 1.14
MA10H
MA10HMA10H

Photos are for reference only; the actual part may show minor variances from the picture

Grease Seal 0.22
MA10D
MA10DMA10D

Photos are for reference only; the actual part may show minor variances from the picture

Lock Washer 4 7/8" x 3 5/16" x ¼" 0.51
MA10B
MA10BMA10B

Photos are for reference only; the actual part may show minor variances from the picture

Trunnion Nut, 3 5/16 "-12 1.35
 Bolt 3/8"-24x2 3/4" Gr8 0.20
 Nut StlLck 3/8"-24x21/64"Ht w/ 9/16"Hex ClrZnc Flag_US 0.01
MA10E
MA10EMA10E

Photos are for reference only; the actual part may show minor variances from the picture

Trunnion Cap 4 Hole W/ 2 Drillable For 6 Hole App. 1.32
 Trunnion Cap 6 Hole 1.32
 End Cap Cast 32.87
MA12A
MA12AMA12A

Photos are for reference only; the actual part may show minor variances from the picture

End Cap, Cast 30.64
MA9C
MA9CMA9C

Photos are for reference only; the actual part may show minor variances from the picture

Lower Load Pad 1 3/4" Pad 10.40
MA9C-U
MA9C-UMA9C-U

Photos are for reference only; the actual part may show minor variances from the picture

Polyurethane Lower Load Pad 1 3/4" Pin Flag_US 8.18
MA10A
MA10AMA10A

Photos are for reference only; the actual part may show minor variances from the picture

Insulator Spacer Block 3.00
MA9E
MA9EMA9E

Photos are for reference only; the actual part may show minor variances from the picture

Upper Load Pad 1 3/4" Pin 7.05
MA9E-U
MA9E-UMA9E-U

Photos are for reference only; the actual part may show minor variances from the picture

Polyurethane Upper Load Pad 1 3/4" Pin Flag_US 6.00
 Upper Load Pad 1 1/4" Pin Flag_US 6.59
MA9M-U
MA9M-UMA9M-U

Photos are for reference only; the actual part may show minor variances from the picture

Polyurethane Upper Load Pad 1 1/4" Pin Flag_MX 5.80
 Washer 7/8"x1 1/2"x1/4" Flag_US 0.08
HE10CV
HE10CVHE10CV

Photos are for reference only; the actual part may show minor variances from the picture

Nut StlLck 7/8"-14x27/32"Ht w/ 1 5/16"Hex ClrZnc 0.18
W78
W78W78

Photos are for reference only; the actual part may show minor variances from the picture

7/8 Ubolt Washer 1.750 x 0.938 x 0.155 ± 0.02 0.06
MA10F
MA10FMA10F

Photos are for reference only; the actual part may show minor variances from the picture

Nut NylLck 7/8"-14x15/16"Ht w/ 1 5/16"Hex ClrZnc 0.22
MA5B
MA5BMA5B

Photos are for reference only; the actual part may show minor variances from the picture

Top Plate, Semi-Round Cast 8.69
W114
W114W114

Photos are for reference only; the actual part may show minor variances from the picture

1-¼ Ubolt Washer 2.500 x 1.375 x 0.155 ± 0.02 0.11
UBP114
UBP114UBP114

Photos are for reference only; the actual part may show minor variances from the picture

4 Each 1 1/4"-12 High Nuts & Washers 3.52
HN114
HN114HN114

Photos are for reference only; the actual part may show minor variances from the picture

Nut Deep 1 1/4"-12x1 11/16"Ht w/ 1 13/16"Hex Gr8 0.75
HN114SP
HN114SPHN114SP

Photos are for reference only; the actual part may show minor variances from the picture

Nut ExtDeep 1 1/4"-12x2 3/4"Ht w/ 1 13/16"Hex Gr8 1.26
HE9W
HE9WHE9W

Photos are for reference only; the actual part may show minor variances from the picture

1 7/8" Taper Stud Cartridge 5.98
  J/9 Leaf Drive Axle Spring Flag_US
Ind Std#WidthLengthLength2EyeEye2ArchLeavesPackThkCapacityComments
62-109425-5/825-5/8PL1 & PL2 1-3/4 DIAPL1 & PL2 1-3/4 DIA5-3/8JP/96-1/817000C TO C ON JACK PLATE 6-1/2,
223.00
  J/10 Leaf Drive Axle Spring Flag_MX
Ind Std#WidthLengthLength2EyeEye2ArchLeavesPackThkCapacityComments
62-11342626PL1 & PL3 1-3/4 DIAPL1 & PL3 1-3/4 DIA7JP/108-3/819000-22000C TO C ON JACK PLATE 6-1/2,
319.00
  9 Leaf Drive Axle Spring Flag_US
Ind Std#WidthLengthLength2EyeEye2ArchLeavesPackThkCapacityComments
62-13742825-5/8PL1 & PL3 1-3/4 DIAPL1 & PL3 1-3/4 DIA695-5/817000,
222.00
  10 Leaf Drive Axle Spring Flag_US
Ind Std#WidthLengthLength2EyeEye2ArchLeavesPackThkCapacityComments
62-13942825-5/8PL1 & PL3 1-3/4 DIAPL1 & PL3 1-3/4 DIA6107-3/834000ANTI-SWAY,
278.50
  11 Leaf Drive Axle Spring Flag_US
Ind Std#WidthLengthLength2EyeEye2ArchLeavesPackThkCapacityComments
62-143430-5/828-1/4PL1 & PL3 1-3/4 DIAPL1 & PL3 1-3/4 DIA6-7/81110-3/819000-22000ANTI-SWAY,
419.00
MA147
MA147MA147

Photos are for reference only; the actual part may show minor variances from the picture

10 Lf Drive Axle Spring USA Flag_US
Ind Std#WidthLengthLength2EyeEye2ArchLeavesPackThkCapacityComments
62-147428-3/826PL1 & PL3 1-3/4 DIAPL1 & PL3 1-3/4 DIA7109-3/819000-22000ANTI-SWAY,
354.70
  10 Leaf Drive Axle Spring Flag_US
Ind Std#WidthLengthLength2EyeEye2ArchLeavesPackThkCapacityComments
62-153428-3/826PL1 & PL3 1-3/4 DIAPL1 & PL3 1-3/4 DIA7-1/4106-7/819000,
265.50
  10 Leaf Drive Axle Spring Flag_US
Ind Std#WidthLengthLength2EyeEye2ArchLeavesPackThkCapacityComments
62-155428-3/826PL1 & PL3 1-3/4 DIAPL1 & PL3 1-3/4 DIA7-1/8107-7/819000-22000,
304.00
  9 Leaf Drive Axle Spring Flag_US
Ind Std#WidthLengthLength2EyeEye2ArchLeavesPackThkCapacityComments
62-1287430-7/828-3/8PL1 & PL3 1-3/4 DIAPL1 & PL3 1-3/4 DIA6-5/8910-1/225000,
439.00
