Parts from
Hutchens H/CH-7600/7650/9600 Series Suspension(49"-54.5" Axle Spacing)

Return To Product Lines & Applications

Pic

Description

HU1B

Photos are for reference only; the actual part may show minor variances from the picture

Add to Comparison List

Fabricated Equalizer w/Bushing use w/ HU10F

Type	Overall Length	Application	Bushing Included	Bushing	Bolt Kit	Bolt Kit w/Bushing
Fab.	16 1/2"	HUTCH	Yes	HU9A	HU10F	HU9A-KIT,

19.80

HU1B-U

Photos are for reference only; the actual part may show minor variances from the picture

Fab Equalizer W/ Poly Bushing use W/ HU10F Flag_US

Type	Overall Length	Application	Bushing Included	Bushing	Bolt Kit	Bolt Kit w/Bushing
Fab.	16 1/2"	HUTCH	Yes	HU9A-U	HU10F	HU9A-U-KIT,

19.47

HU1A

Photos are for reference only; the actual part may show minor variances from the picture

Cast Equalizer W/ Bushing use W/ HU10F

Type	Overall Length	Application	Bushing Included	Bushing	Bolt Kit	Bolt Kit w/Bushing
Cast	16 1/2"	HUTCH	Yes	HU9A	HU10F	HU9A-KIT,

18.90

HU1A-U

Photos are for reference only; the actual part may show minor variances from the picture

Cast Equalizer W/ Poly Bushing use W/ HU10F Flag_US

Type	Overall Length	Application	Bushing Included	Bushing	Bolt Kit	Bolt Kit w/Bushing
Cast	16 1/2"	HUTCH	Yes	HU9A-U	HU10F	HU9A-U-KIT,

19.20

HU1E

Photos are for reference only; the actual part may show minor variances from the picture

Fabricated Equalizer w/Bushing use w/ HU10N

Type	Overall Length	Application	Bushing Included	Bushing	Bolt Kit	Bolt Kit w/Bushing
Fab.	16 1/2"	HUTCH	Yes	HU9F	HU10N	HU9F-KIT,

19.80

U.S. Made Premium Fab Eq w/ Bushing use w/ HU10N Flag_US

19.85

HU1E-U

Photos are for reference only; the actual part may show minor variances from the picture

Fab Equalizer W/ Poly Bushing use W/ HU10N Flag_US

Type	Overall Length	Application	Bushing Included	Bushing	Bolt Kit	Bolt Kit w/Bushing
Fab.	16 1/2"	HUTCH	Yes	HU9F-U	HU10N	HU9F-U-KIT,

20.90

HU1F

Photos are for reference only; the actual part may show minor variances from the picture

Cast Equalizer W/ Bushing use W/ HU10N

Type	Overall Length	Application	Bushing Included	Bushing	Bolt Kit	Bolt Kit w/Bushing
Cast	16 1/2"	HUTCH	Yes	HU9F	HU10N	HU9F-KIT,

20.35

Cast Equalizer W/ Poly Bushing use W/ HU10N Flag_US

20.60

HU10F

Photos are for reference only; the actual part may show minor variances from the picture

Equalizer Hardware Kit

3.10

HU10N

Photos are for reference only; the actual part may show minor variances from the picture

Equalizer Hardware Kit

4.00

HU9A-KIT

Photos are for reference only; the actual part may show minor variances from the picture

Equalizer Bushing Kit Flag_US

4.36

HU9A

Photos are for reference only; the actual part may show minor variances from the picture

Equalizer Bushing used in HU1A & HU1B

2.16

HU9A-U

Photos are for reference only; the actual part may show minor variances from the picture

Polyurethane Equalizer Bushing used in HU1A & HU1B Flag_MX

1.89

HU9F-KIT

Photos are for reference only; the actual part may show minor variances from the picture

Equalizer Bushing Kit Flag_US

5.80

HU9F

Photos are for reference only; the actual part may show minor variances from the picture

Equalizer Bushing used in HU1E & HU1F

3.22

HU9F-U

Photos are for reference only; the actual part may show minor variances from the picture

Polyurethane Equalizer Bushing used in HU1E & HU1F Flag_MX

2.62

HU10G

Photos are for reference only; the actual part may show minor variances from the picture

Equalizer Hardware Kit Flag_US

1.85

HU10B

Photos are for reference only; the actual part may show minor variances from the picture

Bolt Step 5/8"-18 x 6" G5 w/ 3/4"OD Shoulder

0.81

HU10L

Photos are for reference only; the actual part may show minor variances from the picture

Bolt 1 1/8"-7x6-7/8" G5

2.28

HU10A

Photos are for reference only; the actual part may show minor variances from the picture

Nut Steel Lock 5/8"-18x9/16"Ht w/ 15/16"Hex Clear Zinc

0.07

HU10E

Photos are for reference only; the actual part may show minor variances from the picture

Lock Tab

0.09

HU10P

Photos are for reference only; the actual part may show minor variances from the picture

Roller Bolt Kit

0.62

HU4H

Photos are for reference only; the actual part may show minor variances from the picture

Cast Torque Arm(18"-20") W/O Bshgs use W/ (2) HU9C-Kit

Application	C to C	Bushings Included	Bushings - # required	Bushing kits - # required	Material	Type
Hutch	18" to 20"	No		HU9C-KIT-2	CAST	ADJ,

11.02

HU4I

Photos are for reference only; the actual part may show minor variances from the picture

Cast Torque Arm(19 1/4") W/O Bshgs use W/ (2) HU9C-Kit

Application	C to C	Bushings Included	Bushings - # required	Bushing kits - # required	Material	Type
HUTCH	19-1/4"	NO		HU9C-KIT-2	CAST	FIXED,

9.89

HU9C-KIT

Photos are for reference only; the actual part may show minor variances from the picture

Torque Arm Bushing Kit Flag_US

3.00

FR9B

Photos are for reference only; the actual part may show minor variances from the picture

Torque Arm Bushing for Fruehauf(2 req per End)

0.20

FR9B-U

Photos are for reference only; the actual part may show minor variances from the picture

Poly Torque Arm Bushing for Fruehauf(2 req per End) Flag_MX

0.18

Torque Rod Bolt7/8"-14x6 1/16" w/ 1 1/4" Shoulder G5

2.22

HU5A

Photos are for reference only; the actual part may show minor variances from the picture

Top Plate Round Rolled Design

3.65

HU5AW

Photos are for reference only; the actual part may show minor variances from the picture

Top Plate Round Welded Design

4.80

OE Reyco Top Plate Various Models Flag_US

6.15

RE5B

Photos are for reference only; the actual part may show minor variances from the picture

Top Plate, U-Bolt Up Cast

6.65

RET7555

Photos are for reference only; the actual part may show minor variances from the picture

OE Reyco Spacer Block 1/2" 3"x7" Various Models Flag_US

2.80

RET7716

Photos are for reference only; the actual part may show minor variances from the picture

OE Reyco Spacer Block Various Models Flag_US

3.46

RE2D

Photos are for reference only; the actual part may show minor variances from the picture

Spacer Block 3"x7 1/2"x1" Cast Steel

2.10

RE913901

Photos are for reference only; the actual part may show minor variances from the picture

OE Reyco Bottom Plate 21B Flag_US

7.55

RE3A

Photos are for reference only; the actual part may show minor variances from the picture

Bottom Plate, 5" Rd Cast

7.00

HU774701

Photos are for reference only; the actual part may show minor variances from the picture

Bottom Plate, 5" Sq Cast OEM Hutch Flag_US

8.00

HU3G

Photos are for reference only; the actual part may show minor variances from the picture

Bottom Plate, 5" Sq Cast

8.00

HU2A

Photos are for reference only; the actual part may show minor variances from the picture

Axle Seat, 3/4" High 5" Rd Fab

5.70

HU2B

Photos are for reference only; the actual part may show minor variances from the picture

Axle Seat, 1 1/4" High 5" Rd Fabricated

6.40

HU2C

Photos are for reference only; the actual part may show minor variances from the picture

Axle Seat 3/4" High 4 x 6 Sq Fab

5.94

HU2D

Photos are for reference only; the actual part may show minor variances from the picture

Axle Seat, Fab 1 1/4" High 4 x 6 Sq

7.33

HU2E

Photos are for reference only; the actual part may show minor variances from the picture

Axle Seat, 3/4" High 5 x 5 Sq Fabricated

5.55

HU2F

Photos are for reference only; the actual part may show minor variances from the picture

Axle Seat, 1 1/4" High 5 x 5 Sq Fabricated

6.63

HU2G

Photos are for reference only; the actual part may show minor variances from the picture

Axle Seat, 2 1/4" High 5" Rd Fabricated

8.93

HU2H

Photos are for reference only; the actual part may show minor variances from the picture

Axle Seat, 4 3/4" High, 5" Rd Fabricated

13.07

HU2K

Photos are for reference only; the actual part may show minor variances from the picture

Axle Seat, 3 1/4" High, 5" Rd Fabricated Flag_US

10.64

HU2L

Photos are for reference only; the actual part may show minor variances from the picture

Axle Seat, 2 3/4" High 4 x 6 Sq Fabricated

10.52

HU2M

Photos are for reference only; the actual part may show minor variances from the picture

No Hop Axle Seat 3/4" High 5" Rd Fab

4.95

HU2N

Photos are for reference only; the actual part may show minor variances from the picture

Axle Seat, 2 1/4" High 4 x 6 Sq Fabricated

6.68

HU2O

Photos are for reference only; the actual part may show minor variances from the picture

Axle Seat, 1 3/4" High 5" Rd

7.06

HU2Q

Photos are for reference only; the actual part may show minor variances from the picture

Axle Seat 1 3/4" High 4x6 Axle

6.45

HU7E

Photos are for reference only; the actual part may show minor variances from the picture

Center Straddle Mount Hanger Cast

16.92

HU7G

Photos are for reference only; the actual part may show minor variances from the picture

Center Under Mount Hanger Fabricated Flag_US

24.66

HU7L

Photos are for reference only; the actual part may show minor variances from the picture

Center Straddle Mount Hanger Fabricated

15.68

Center Straddle Mount Hanger Fabricated

15.70

HU7O

Photos are for reference only; the actual part may show minor variances from the picture

Center Under Mount Hanger Fabricated

15.73

HU8D

Photos are for reference only; the actual part may show minor variances from the picture

LH Rear Under Mount Hanger Cast Flag_US

13.39

HU8E

Photos are for reference only; the actual part may show minor variances from the picture

RH Rear Under Mount Hanger Cast Flag_US

13.39

HU8H

Photos are for reference only; the actual part may show minor variances from the picture

LH Rear Flange Mount Hanger Cast Flag_US

16.20

HU8I

Photos are for reference only; the actual part may show minor variances from the picture

RH Rear Flange Mount Hanger Cast Flag_US

15.60

Center Hanger Flag_US

17.99

HU10J

Photos are for reference only; the actual part may show minor variances from the picture

Wear Pad

1.69

UKRD7103G8

Photos are for reference only; the actual part may show minor variances from the picture

Ubolt Kit, Rd 7/8"x10"x3"W G8 (2 Bolts, 4 Nuts, & 4 Washers) Flag_US

9.06

UKRD7113G8

Photos are for reference only; the actual part may show minor variances from the picture

Ubolt Kit, Rd 7/8"x11"x3"W G8 (2 Bolts, 4 Nuts, & 4 Washers) Flag_US

9.36

UKRD7123

Photos are for reference only; the actual part may show minor variances from the picture

Ubolt Kit, Rd 7/8"x12"x3"W (2 Bolts, 4 Nuts, & 4 Washers) Flag_US

9.60

UKRD7123G8

Photos are for reference only; the actual part may show minor variances from the picture

Ubolt Kit,Rd 7/8"x12"x3"W G8 (2 Bolts, 4 Nuts, & 4 Washers) Flag_US

10.04

UKRD7125

Photos are for reference only; the actual part may show minor variances from the picture

Ubolt Kit, Rd 7/8"x12"x5"W (2 Bolts, 4 Nuts, & 4 Washers) Flag_US

10.56

UKRD7133

Photos are for reference only; the actual part may show minor variances from the picture

Ubolt Kit, Rd 7/8"x13"x3"W (2 Bolts, 4 Nuts, & 4 Washers) Flag_US

10.30

UKRD7135

Photos are for reference only; the actual part may show minor variances from the picture

Ubolt Kit, Rd 7/8"x13"x5"W (2 Bolts, 4 Nuts, & 4 Washers) Flag_US

11.16

UKRD7143

Photos are for reference only; the actual part may show minor variances from the picture

Ubolt Kit, Rd 7/8"x14"x3"W (2 Bolts, 4 Nuts, & 4 Washers) Flag_US

11.00

UKRD7145

Photos are for reference only; the actual part may show minor variances from the picture

Ubolt Kit, Rd 7/8"x14"x5"W (2 Bolts, 4 Nuts, & 4 Washers) Flag_US

11.76

UKRD7153

Photos are for reference only; the actual part may show minor variances from the picture

Ubolt Kit, Rd 7/8"x15"x3"W (2 Bolts, 4 Nuts, & 4 Washers) Flag_US

11.20

UKRD7155

Photos are for reference only; the actual part may show minor variances from the picture

Ubolt Kit, Rd 7/8"x15"x5"W (2 Bolts, 4 Nuts, & 4 Washers) Flag_US

12.36

UKRD7163

Photos are for reference only; the actual part may show minor variances from the picture

Ubolt Kit, Rd 7/8"x16"x3"W (2 Bolts, 4 Nuts, & 4 Washers) Flag_US

12.44

UKRD7163G8

Photos are for reference only; the actual part may show minor variances from the picture

Ubolt Kit,Rd 7/8"x16"x3"W G8 (2 Bolts, 4 Nuts, & 4 Washers) Flag_US

12.44

UKRD7165

Photos are for reference only; the actual part may show minor variances from the picture

Ubolt Kit, Rd 7/8"x16"x5"W G5 (2 Bolts, 4 Nuts, & 4 Washers)

13.30

UKRD7165G8

Photos are for reference only; the actual part may show minor variances from the picture

Ubolt Kit, Rd 7/8"x16"x5"W G8 (2 Bolts, 4 Nuts, & 4 Washers) Flag_US

13.26

UKRD7183G8

Photos are for reference only; the actual part may show minor variances from the picture

Ubolt Kit,Rd 7/8"x18"x3"W G8 (2 Bolts, 4 Nuts, & 4 Washers) Flag_US

13.00

UKSQ7105G8

Photos are for reference only; the actual part may show minor variances from the picture

Ubolt Kit, Sq 7/8"x10"x5"W G8 (2 Bolts, 4 Nuts, & 4 Washers) Flag_US

9.66

UKSQ7145G8

Photos are for reference only; the actual part may show minor variances from the picture

Ubolt Kit, Sq 7/8"x14"x5"W G8 (2 Bolts, 4 Nuts, & 4 Washers) Flag_US

11.60

UKSQ7165G8

Photos are for reference only; the actual part may show minor variances from the picture

Ubolt Kit, Sq 7/8"x16"x5"W G8 (2 Bolts, 4 Nuts, & 4 Washers) Flag_US

13.26

UKRD3103G8

Photos are for reference only; the actual part may show minor variances from the picture

Ubolt Kit, Rd 3/4"x10"x3"W G8 (2 Bolts, 4 Nuts, & 4 Washers) Flag_US

6.94

UKRD3123G8

Photos are for reference only; the actual part may show minor variances from the picture

Ubolt Kit, Rd 3/4"x12"x3"W G8 (2 Bolts, 4 Nuts, & 4 Washers) Flag_US

7.25

UKRD3143G8

Photos are for reference only; the actual part may show minor variances from the picture

Ubolt Kit, Rd 3/4"x14"x3"W G8 (2 Bolts, 4 Nuts, & 4 Washers) Flag_US

8.10

UKRD3163G8

Photos are for reference only; the actual part may show minor variances from the picture

Ubolt Kit, Rd 3/4"x16"x3"W G8 (2 Bolts, 4 Nuts, & 4 Washers) Flag_US

9.57

UKRD3183G8

Photos are for reference only; the actual part may show minor variances from the picture

Ubolt Kit, Rd 3/4"x18"x3"W G8 (2 Bolts, 4 Nuts, & 4 Washers) Flag_US

10.10

Trailer Spring 1 Leaf

Ind Std#	ArchClass	Width	Length	Length2	Eye	Eye2	Arch	Leaves	PackThk	Capacity	Comments
	LOW	3	21-7/8	23-1/4			4-11/16	1	1-3/8	11200	,

45.00

Trailer Spring 1 Leaf

Ind Std#	ArchClass	Width	Length	Length2	Eye	Eye2	Arch	Leaves	PackThk	Capacity	Comments
	HIGH	3	22-1/2	24-3/16	HOOK	HOOK	7-1/16	1	1-3/8	11200	,

36.00

HU2260

Photos are for reference only; the actual part may show minor variances from the picture

Trailer Spring 8 Leaf

Ind Std#	ArchClass	Width	Length	Length2	Eye	Eye2	Arch	Leaves	PackThk	Capacity	Comments
	HIGH	3	21-3/8	23-1/8	PL3 HOOK		4-15/16	8	4	12000	,

101.00

Trailer Spring 7 Leaf

Ind Std#	ArchClass	Width	Length	Length2	Eye	Eye2	Arch	Leaves	PackThk	Capacity	Comments
	HIGH	3	21-3/8	23-1/8	PL3 HOOK		4-15/16	7	3-1/2	11200	,

91.20

HU2706

Photos are for reference only; the actual part may show minor variances from the picture

Trailer Spring 7 Leaf

Ind Std#	ArchClass	Width	Length	Length2	Eye	Eye2	Arch	Leaves	PackThk	Capacity	Comments
TRA2706	LOW	3	20-3/4	22-3/8	PL3 HOOK		2-3/4	7	3-1/2	11200	,

92.00

Trailer Spring 7 Leaf Flag_US

Ind Std#	ArchClass	Width	Length	Length2	Eye	Eye2	Arch	Leaves	PackThk	Capacity	Comments
TRA2707	HIGH	3	23-1/8	23-1/8	PL3 HOOK		5-1/2	7	3-1/2	11200	TURNED BACK ENDS,

94.00

Trailer Spring 8 Leaf Flag_MX

Ind Std#	ArchClass	Width	Length	Length2	Eye	Eye2	Arch	Leaves	PackThk	Capacity	Comments
TRA2708	HIGH	3	21-3/8	23-1/8	PL3 HOOK	PL3 HOOK	4-15/16	8	4	12000	,

103.20

Trailer Spring 8 Leaf Flag_US

Ind Std#	ArchClass	Width	Length	Length2	Eye	Eye2	Arch	Leaves	PackThk	Capacity	Comments
TRA2710	HIGH	3	23-1/8	23-1/8		PL3 HOOK	5-1/2	8	4	12000	,

104.90

HU2716

Photos are for reference only; the actual part may show minor variances from the picture

Trailer Spring 7 Leaf

Ind Std#	ArchClass	Width	Length	Length2	Eye	Eye2	Arch	Leaves	PackThk	Capacity	Comments
TRA2716	HIGH	3	21-3/8	23-1/8	PL3 HOOK	PL3 HOOK	4-15/16	7	3-1/2	11200	,

95.00

Trailer Spring 8 Leaf Flag_US

Ind Std#	ArchClass	Width	Length	Length2	Eye	Eye2	Arch	Leaves	PackThk	Capacity	Comments
TRA2718	LOW	3	22-3/8	22-3/8		PL3 HOOK	3	8	4	12000	,

104.00

HU2726

Photos are for reference only; the actual part may show minor variances from the picture

Trailer Spring 3 Leaf

Ind Std#	Width	Length	Length2	Eye	Eye2	Arch	Leaves	PackThk	Capacity	Comments
TRA-2726	3	22-1/2	23-5/8	PL1 Hook S.E.	PL1 Hook L.E.	6	3Lf/788	2-1/2	11200	,

55.00

Trailer Spring HD 4 Leaf Flag_MX

Ind Std#	Width	Length	Length2	Eye	Eye2	Arch	Leaves	PackThk	Capacity	Comments
TRA-2726HD	3	22-1/2	23-5/8	PL1 Hook S.E	PL1 Hook L.E.	6	4Lf/788	3-5/16	14000	,

70.60

HU2727

Photos are for reference only; the actual part may show minor variances from the picture

Trailer Spring 3 Leaf

Ind Std#	Width	Length	Length2	Eye	Eye2	Arch	Leaves	PackThk	Capacity	Comments
TRA-2727	3	21-3/4	22-7/8	PL1 Hook S.E.	PL1 Hook L.E.	4-1/2	3Lf/788	2-1/2	11200	,

53.00

Trailer Spring HD 4 Leaf Flag_MX

Ind Std#	Width	Length	Length2	Eye	Eye2	Arch	Leaves	PackThk	Capacity	Comments
TRA-2727HD	3	21-3/4	22-7/8	PL1 Hook S.E.	PL1 Hook L.E.	3-3/4	4Lf/788	3-5/16	14000	,

68.00

HU2728

Photos are for reference only; the actual part may show minor variances from the picture

Trailer Spring 3 Leaf

Ind Std#	Width	Length	Length2	Eye	Eye2	Arch	Leaves	PackThk	Capacity	Comments
TRA-2728	3	21-1/4	22-7/16	PL1 Hook S.E.	PL1 Hook L.E.	3-5/8	3Lf/788	2-1/2	11200	,

52.60

Trailer Spring HD 4 Leaf Flag_MX

Ind Std#	Width	Length	Length2	Eye	Eye2	Arch	Leaves	PackThk	Capacity	Comments
TRA-2728HD	3	21-1/4	22-7/16	PL1 Hook S.E.	PL1 Hook L.E.	2-7/8	4Lf/788	3-5/16	14000	,

68.00

Trailer Spring 8 Leaf

Ind Std#	ArchClass	Width	Length	Length2	Eye	Eye2	Arch	Leaves	PackThk	Capacity	Comments
TRA2732	LOW	3	20-3/4	22-3/8	PL3 HOOK		8	8	4	12000	,

99.00

HU2740

Photos are for reference only; the actual part may show minor variances from the picture

Trailer Spring 3 Leaf

Ind Std#	ArchClass	Width	Length	Length2	Eye	Eye2	Arch	Leaves	PackThk	Capacity	Comments
	HIGH	3	22	23-3/4	PL1 HOOK	PL1 HOOK	5-1/2	3	2-15/16	12000	,

62.30

HU2741

Photos are for reference only; the actual part may show minor variances from the picture

Trailer Spring 3 Leaf

Ind Std#	ArchClass	Width	Length	Length2	Eye	Eye2	Arch	Leaves	PackThk	Capacity	Comments
	LOW	3	21-1/2	22-3/4	PL1 HOOK	PL1 HOOK	3-1/4	3	2-15/16	12000	,

63.90

Trailer Spring 2 Leaf

Ind Std#	ArchClass	Width	Length	Length2	Eye	Eye2	Arch	Leaves	PackThk	Capacity	Comments
	HIGH	3	22-1/2	24	PL1 HOOK	PL1 HOOK	6-3/4	2	1-15/16	11200	,

47.50

HU2753

Photos are for reference only; the actual part may show minor variances from the picture

Trailer Spring 2 Leaf

Ind Std#	ArchClass	Width	Length	Length2	Eye	Eye2	Arch	Leaves	PackThk	Capacity	Comments
TRA2753	MEDIUM	3	21-7/8	23-1/2	PL1 HOOK	PL1 HOOK	5-1/4	2	1-15/16	11200	,

48.00

Trailer Spring 2 Leaf

Ind Std#	ArchClass	Width	Length	Length2	Eye	Eye2	Arch	Leaves	PackThk	Capacity	Comments
	LOW	3	21-5/8	23-1/4	PL1 HOOK	PL1 HOOK	4-1/4	2	1-15/16	11200	,

48.80

Trailer Spring 1/1 Leaf Flag_MX

Ind Std#	ArchClass	Width	Length	Length2	Eye	Eye2	Arch	Leaves	PackThk	Capacity	Comments
TRA2757	MEDIUM	3	21-1/2	23-1/4	PL2 HOOK		4-7/8	1/1	2-9/16	11200	TWO STAGE,

66.00

Products listed are suggested parts and may not fit every applications. Please verify parts prior to ordering.

Please use this Feedback Form if you have any comments or suggestions, or suspect any inaccuracies in our data.
